Mini recuperator with remote control EHRV100P, Ø100 mm

  • with remote control
  • method of operation - 1 min. air is blown out of the room, 1 min. into the room, heat exchanger absorbs the exhaust air heat and transmits to supplying air
  • maximum efficiency: 1 speed - 89.39 %, 2 speed - 87.90 %
  • especially economical - uses only 1.5-2.0 W power
  • two speed motor
  • aluminum heat exchanger
  • adjustable duct: 335 mm - 540 mm
  • made in Poland
  • 2 years warranty



EHRV installation

  1. supply/extract fan
  2. fan cover
  3. screw covering
  4. power supply compartment
  5. fan mounting screw caps
  6. two speed fan pull chain switch
  7. telescoping vent duct for easy adjustment to the wall thickness
  8. aluminum accumulative heat exchanger
  9. air filter
  10. external ventilation grille
  11. screw caps


Brand: ESEM

Code
Speed
Noise level, dB(A)3m
Capacity, m³/h
Power, W
Protection class IP
EHRV100 I 32 30 1.5 X4
II 36 45 2.0
